Convertor 24V-->230V (500W)

Convertor 24V-->230V (500W)

Inverter for 24V battery of car and boat. It will invert the 24V DC current to 230V AC. With this device 230V equipment can be connected anywhere! The inverter is equipped with a very high peak output power and has got the E-mark approval, which is obliged since October 2002.
Output power continue: 300 Watt
30 minutes max load: 350 Watt
Surge output power: 600 Watt
Input: DC 20~30V
Output: AC 230V
Output waveform: Modified sine wave
Output frequency: 50 Hz
Stand by current: < 0.2 A
Efficiency: 90 %

Protections:
* Output short
* Input polarity reverse (by fuse)
* High DC input voltage
* Battery low alarm: DC 21 +/- 0.8 V
* Battery low shutdown: DC 20 +/- 0.8 V
* Overtemperature: 60 +/- 5 degrees Celsius
* Overload

Fuse:
* Battery cord 20A 1pc
* Cigarette plug 10A 1pc

Cooling by fan if:
* Temperature reaches 40 degrees Celsius
* Overload reaches 2/3

AC output: One Schuko socket
Size (LxWxH)): 163x90x75mm
